Introduction

• No. S246-3C
• Product Name S246-3C
• Description
  . Zinc alloy die cast housing and cylinder.
  . Bright chrome plated standard.
  . Stainless steel capped bezel, dust shutter mechanism.
  . 5 disc tumbler mechanism.
  . Reversible double-bitted brass keys, nickel plated.
  . Silver plated contacts and terminals.
  . 2 position (off-on) 3 terminals.
  . Hex nut mounted.


  SPECIFICATION
  . Contact Rating: 4A 125VAC, 2A 250VAC
  . Contact Resistance: 10 Milli-Ohms Max.
  . Insulation Resistance: 500 Meg-Ohms Min. (500VDC)
  . Dielectric Strength: 1000 VAC - 1 Minute.
