Introduction

• No. S2123
• Product Name S2123
• Description
  . Zinc alloy die cast housing and cylinder.
  . Bright chrome plated standard.
  . 7 pin tumbler mechanism.
  . Steel made tubular keys, nickel plated.
  . Silver plated contacts and terminals.
  . 2 position (off-on) 2 spade terminals,
  . Hex nut mounted.


  SPECIFICATION
  . Contact Rating: 4A 125VAC, 2A 250VAC.
  . Contact resistance: 50Milli - Ohms Max.
  . Insulation Resistance: 500 Meg - Ohms Min. (500VDC)
  . Dielectric Strength: 1500VAC - 1 Minute.
